Vacuum pump

Vacuum generator

Vacuum generator
Robust & powerful

-980 mbar (-15 psi)

Long lifespan

Anticorrosive coating & oil free

Low noise & vibration

42 dB

Features & benefits

High efficiency and long lifespan vacuum pump

This high accuracy microfluidic vacuum source generates negative pressure for microfluidic flow control without installation/connection of any instrument.

The anticorrosive coating of the receiver ensures a long lifespan of the instruments.

Elveflow has selected a totally oil free, low noise, high efficiency and long lifespan vacuum pump to be used as vacuum source for the OB1 pressure controller.

The Vacuum Pump is available in two versions: 230V/50Hz or 110V/60Hz

Specifications are compared to the compact Elveflow Vacuum Source.

Vacuum Pump (KVP-230 / KVP-110)

Elveflow Vacuum Source (EVS)
Performances
Vacuum pressure (relative) -980 mbar (-15 psi) -850 mbar(13 psi)
Vacuum pressure (absolute) 20 mbar (0,1 psi) 150 mbar (2.3 psi)
Pumping speed 18 L/min 8 L/min at 0 bar
Noise level <42 dB <53 dB
Mechanical specifications
Dimensions (l x w x h) 30 x 17 x 24 cm 16.1 x 19.4 x 19.5 cm
Weight 3 kg 1.4 kg
Pneumatic connection 6 mm push-in
Internal receiver volume – 250 mL
Operating temperature – 5-40°C
Operating humidity – up to 80%
Electrical specifications
Input voltage range – 24 V
AC supply frequency – 50-60 Hz
Power supply voltage 100 – 240 vac
Max current consumption 1.5 A (typical: 0.8 A)
Max power consumption 140 W 36 W
